Marine - AIS Fishing Buoy
Product Overview
Our AIS Fishing Buoy is a cutting-edge marine navigation aid designed for precise vessel and equipment tracking. With advanced GPS positioning and AIS transmission capabilities, it provides reliable location data in various marine conditions.
Key Features
- ✓High-precision GPS positioning with fast start times
- ✓Long-range transmission capability up to 18nm
- ✓Extended battery life with multiple power modes
- ✓IP68 waterproof rating for marine environments
- ✓Programmable transmission intervals
- ✓Compatible with AIS buoy receiver WR100
Technical Specifications
Parameters
TX frequency
161.975MHz & 162.025MHz
Band width
25KHz
Stability
±1ppm
Voltage
6.2～8.2VDC
Current consumption
≤0.3mA (Standby), ≤25mA (GPS searching), ≤2A (Tx)
GPS start time
≤60s (Cold start), ≤5s (Hot start)
GPS positioning accuracy
≤10m
Environment
Temperature
-25℃~60℃
Waterproof
IP68
AIS TX
TX Power
10W
Adjust Mode
GMSK BT=0.4
Adjust Index
0.5
Launch Stray
<-36dBm
Function
Antenna
Internal antenna
Distance
W150：≥12nm (10W)
W151：≥18nm (12W)
Tx interval time
30s / 1min / 2min / 3min / 5min (Programmable)
Battery
Standard (2600mAh)
Working time (Tx interval time:2min)
≥14days
Encrypted version
Using with AIS buoy receiver WR100
Installation & Support
Professional installation service available. Our team provides comprehensive support for setup, calibration, and maintenance. Contact us for detailed information about compatibility with your vessel.
